XST Standby UPS
400VA-800VA
120VAC
Safeguard your computer from power outages with dependable power protection.
The compact XST is a single phase standby UPS designed to deliver power protection to small routers, switches, desktop PCs, VoIP equipment, phone systems, and point of sale equipment. A vital addition to any home office, it enables graceful shutdown of equipment during a longer power outage.
Product Snapshot
- Available models: 400VA, 600VA, 800VA
- Compact size and lightweight design
- RoHS compliant
- Floor, desk, or wall mount
- Primary applications: home or small office, desktop computers, routers, switches, and telecom closets
- 2 years electronics, 2 years battery warranty (USA and Canada)
[table colalign=”left|left|center|center|center”]
,MODEL NUMBER,XST-400,XST-600,XST-800
INPUT,Capacity,400VA (240W),600VA (360W),800VA (480W)
,Voltage,120VAC[attr colspan=”3″]
,Frequency,60Hz[attr colspan=”3″]
OUTPUT,Voltage,120VAC[attr colspan=”3″]
,Waveform,”Sine wave (normal), simulated sine wave (battery mode)”[attr colspan=”3″]
,Frequency,60Hz ± 1Hz[attr colspan=”3″]
,Transfer time,2–6ms[attr colspan=”3″]
BATTERY,Battery type,”Sealed, maintenance free lead acid”[attr colspan=”3″]
,Battery quantity and size,(1) 12V 4.5AH,(1) 12V 7AH,(1) 12V 9AH
,Recharge,8 hours to 90% capacity[attr colspan=”3″]
PHYSICAL,UPS dimensions (W x D x H),3.2 x 8.9 x 8.1 in (vertical stand position)[attr colspan=”3″]
,Shipping dimensions,4.7 x 11.4 x 11.0 in[attr colspan=”3″]
,UPS weight, 4.8 lbs,5.9 lbs,6.8 lbs
,Shipping weight,5.6 lbs,6.7 lbs,7.6 lbs
,Line cord,”5 ft, 5–15P”[attr colspan=”3″]
,Receptacles,(4) NEMA 5–15R[attr colspan=”3″]
ENVIRONMENT,Operating temperature,32–104°F (0–40°C)[attr colspan=”3″]
,Humidity,0–90%[attr colspan=”3″]
,Altitude,”11,500 ft above sea level”[attr colspan=”3″]
INDICATORS & ALARMS,AC mode,Blue LED ON[attr colspan=”3″]
,Battery mode,Blue LED flashes every 10 sec; audible alarm flashes every 10 sec[attr colspan=”3″]
,Low battery,Blue LED flashes every sec; red LED ON; audible alarm flashes every sec[attr colspan=”3″]
,Fault,Red LED ON; continuous audible alarm[attr colspan=”3″]
,Over temperature protection,Red LED flashes every 0.5 sec[attr colspan=”3″]
WARRANTY,,”2 years electronics, 2 years battery (USA and Canada)”[attr colspan=”3″]
COMMUNICATIONS INTERFACE,,None,USB[attr colspan=”2″]
INCLUDED IN BOX,,User manual,”ViewPower CD, USB cable, user manual”[attr colspan=”2″]
[/table]
[table colwidth=”75″]
,Model,Description,Unit Weight, Unit Dimensions
,SNMP-USB,External Web/SNMP Card,1 lb,7.25″ x 6″ x 2.5″
[/table]
